Electron microscopy

The electron microscopy (EM) unit of the Leibniz-IZW is a central facility within the institute and open to all research groups as well as to external collaborators. The Leibniz-IZW has two electron microscopes: A transmission electron microscope (“Tecnai G2 Spirit BioTWIN”, 120 kV, FEI) equipped with a side mounted 2k (Veleta, Olympus-SIS) and a bottom mounted 4k (TIA, FEI) digital camera and a field emission scanning electron microscope (“Gemini Supra 40 VP“, Zeiss). They enable us to investigate finest structures of the smallest dimension in high resolution. Routinely, TEM samples are resin-embedded for ultra-thin sections, but immuno-EM can also be performed. For the investigation of possible viral infections, negative staining of homogenised fresh tissue or faecal samples is applied. Thanks to a variable pressure mode of the scanning electron microscope, fresh samples can be visualised without fixation or conductive coating.

Click here do download more information about this service and our quality management.

Contact

Dr Gudrun Wibbelt
Phone: +49(0)30 5168211
Email: wibbelt@izw-berlin.de
